BEILOCKERY Automatic Tape Wrapping Machine Compact Handheld Wiring Harness Tape Winding Machine with LCD Display for φ0.12inch-φ0.98inch Wire Harness

BEILOCKERY Automatic Tape Wrapping Machine Compact Handheld Wiring Harness Tape Winding Machine with LCD Display for φ0.12inch-φ0.98inch Wire Harness

Stepper motor drive: The tape winding machine adopts a 4500r/min stepper motor drive, which can quickly start and stop, meet the long-term continuous work requirements, and ensure the stability and continuity of production Space saving design: The device is compact in size, does not occupy too much production space, and has flexible layout; Suitable for processing wires with a diameter of 0.12 "-0.98" (3mm-25mm) in industrial environments Intelligent parameter setting and display: The automatic tape wrapping machine can accurately set the number of rolls and speed, and has clear output display function for precise operation monitoring Suitable for long wire harness processing: Adopting an optimized solution, it is more suitable for continuous winding of long wires (length greater than 20in/50cm), and ensures that every inch of the harness can receive uniform winding processing Multiple winding mode switching: The electric tape wrapper supports flexible switching of different winding modes, such as point winding, multi segment winding, continuous winding, etc., to meet diverse winding needs

Product Parameters:

Model: WX-303X

Voltage: 110V

Diameter of wire: 0.12-"0.98"(3mm-25mm)

Main engine speed: 4500r/min

Tape diameter: ≤ 3.9"(100mm)

Tape width: 0.2"-1"(5mm-25mm) (other sizes can be customized)

The inner hole size of the tape: Φ37mm, Φ32mm;

usually Φ37mm (Please inform us of other sizes in advance)

Winding length: Infinite length (More suitable for winding long wires, preferably longer than 20in/50cm)

Scope of applicaiton: High temperature tape, mica tape, ceramic tape, PVC, vinyl, velvet cloth tape, acetate tape, electrical tape‌

Net weight/Gross weight: 106.9lbs(48.5kg) / 134.5lbs(61kg)

Item Included (053044)

Tape Winding Machine *1

Hex Wrenches *9

Foot Switch *1

Power Cord *1
