BGA Rework Station IR6500 1250w Hot Air Soldering Reflow Station with Temp Sensor, Adjustable 8 Temp Welder Infrared Reballing Station Soldering

BGA Rework Station IR6500 1250w Hot Air Soldering Reflow Station with Temp Sensor, Adjustable 8 Temp Welder Infrared Reballing Station Soldering

【Innovation Design】 This BGA rework sation effectively solves the problem that the general infrared rework station is easily affected by airflow leads to inaccurate temperature control, and can easily deal with lead-free soldering rework. 【Integrated Workbench】 Our solder reflow station is small in size but powerful in function, without cable mixing and disorder. Its linear guide-type bracket with abnormality poles can be adjusted and locked by rotating the handle, and it is very convenient to fix the PCB board, which can effectively prevent the PCB board from deformation. 【Excellent Temperature Control】 With 8 rising temperature segments, 8 thermostatic segments, 10 saveable temperature profiles, two upper and lower temperature heaters, and sensitive temperature measuring sensors, the temperature of the operating process can be controlled easily and precisely. In addition, closed-loop temperature control technology ensures precise temperature processes and uniform heat distribution. 【Easy to Control】 The welder infrared reballing station can be connected to a computer, and can be controlled more conveniently with a built-in USB connector and proprietary software. 【Powerful Function】 You can use our soldering system infrared reballing Machine to easily rework a variety of CPU seats, and shielded enclosures, replace various component slots, and easily handle lead-free solder rework.

Application

This product is suitable for laptop motherboards, desktop computer motherboards, server motherboards, industrial computer motherboards, various types of game motherboards, communication equipment motherboards, LCD TVs, and other large circuit boards BGA rework.

Specification

Color: Black

Style: Modern

Material: Aluminum Alloy, Iron

Process: Oxidation, Spray Coating

Assembly Required: No

Power Source: Corded Electric

Heating: IR

Upper Heating: IR

Bottom Heating: IR

Upper Heating Consumption: 400W

Bottom Heating Consumption: 800W

General Power: 1250W

Upper Control Mode: Independent temperature control, high-precision closed-loop control, precision ± 0.5%,Alarm.

Bottom Control Mode: Independent temperature control, high-precision closed-loop control, precision ± 0.5%, No Alarm.

SMD: Suit for welding, removing, or repairing package devices, such as BGA, PBGA, CSP, multi-layer substrates, EMI metallic shield products, solder / lead-free rework, and welding.

Upper Heating Size: 80*80 mm/ 3.15*3.15in

Bottom Heating Size: 180*180mm/ 7.09*7.09in

Applicable Chip Size: ≤70*70 mm/ 2.76*2.76in

Applicable PCB Size: ≤400*305 mm/ 15.75*12.01in

Product Size: 47.5*48*42 cm/ 18.7*18.9*16.54in

Plug Type: US Standard

Power:110V

Package Included

1* BGA Rework Station

1* Power Cord

1* Sensor Wire

1 Roll* Tinfoil

1* USB Cable

1* English Manual
