AITRIP 2PCS USB-C ESP-32 Development Board CP2102 Chip+2PCS 0.96 Inch OLED I2C IIC Display Module 12864 Pixel SSD1306 OLED Screen Board with 30pcs

AITRIP 2PCS USB-C ESP-32 Development Board CP2102 Chip+2PCS 0.96 Inch OLED I2C IIC Display Module 12864 Pixel SSD1306 OLED Screen Board with 30pcs

ESP-32 Development Board USB-C, 2.4GHz Dual Mode WiFi+Bluetooth Dual Core Microcontroller for Arduino IDE, Support AP/STA/AP+STA, CP2102 Chip;ESP-32 development board integrates a dual-core 32-bit processor running at up to 240 MHz, providing impressive processing power. The esp32 usb c offers a rich set of peripheral interfaces, including GPIO, UART, SPI, I2C, and more, allowing for easy connectivity to a wide range of sensors;ESP-32 development board integrates a dual-core 32-bit processor running at up to 240 MHz, providing impressive processing power. 0.96 inch,Resolution: 128 x 64, View angle: > 160°, Support voltage: 3.3V-5V DC, Power consumption: 0.04W during normal operation, full screen lit 0.08W 0.96 Inch OLED I2C IIC Display Module:Embedded Driver IC: SSD1306. Communication: I2C/IIC Interface, only need two I / O ports; It compatibles with R3 board and Mega, Raspberry pi, 51 MCU, STIM 32, etc. Package： 2PCS ESP32 30Pin CP2102 Type C Development Board+ 2PCS 0.96 Inch OLED I2C IIC Display Module 12864 128x64 Pixel SSD1306 Mini Self-Luminous OLED Screen Board+1PCS Type-C Cable 30CM+1X 20-pin male to female jumper wires, 1X 20-pin male to male jumper wires, 1x20-pin female to female jumper wires

ESP32 Kit Compatible with Arduino Projects

ESP-WROOM-32 Development Board USB-C：

ESP32 integrates antenna, switches, RF balun, power amplifiers, low noise amplifiers, filters and power management modules.

Support many kinds of interfaces such as UART/SPI/I2C/PWM/DAC/ADC.

Built-in Wi-Fi and bluetooth

Dual core, this means it has 2 processors.

The clock frequency can go up to 240MHz and it has a 512 kB RAM.

The board offers a rich set of peripheral interfaces, including GPIO, UART, SPI, I2C.

With 2.4GHz WiFi+Bluetooth Dual-mode, support STA/AP/STA+AP mode, universal AT command, easy to use.

0.96 Inch OLED Display Screen Module：

Specifications:

Display Type: OLED (Organic Light Emitting Diode)

Resolution: 128x64 pixels

Interface: I2C Operating Voltage: 3.3V - 5V

Minimum Visible Angle: 160 Degree

Energy Consumption (Normally): 0.06w

View Angle：>160°

Diyplay Dimensions: 0.91 inches (diagonal)

Working Temperature: -20°C to 60°C

Driver IC: SSD1306 Displya

Color: Blue and Yellow

Package：

2X 30Pin CP2012 USB C ESP32 ESP-32S ESP-WROOM-32

2X 0.96 Inch OLED Display Screen Module

1X 20-pin male to female jumper wires,

1X 20-pin male to male jumper wires,

1x20-pin female to female jumper wires

1X Type-C USB cabel
