DMiotech 30A Thermal Circuit Breaker 125/250V AC 50V DC 50/60Hz Push Button Manual Reset Overload Protector Switch for Overload Protection Application

DMiotech 30A Thermal Circuit Breaker 125/250V AC 50V DC 50/60Hz Push Button Manual Reset Overload Protector Switch for Overload Protection Application

APPLICATION:Circuit breakers are widely used in household and commercial appliances, small generators, air compressors, automobiles, electric vehicles, power tools, extension cords, transportation, ships, telecommunications, power strips, audio-visual and power supply, industrial and marine industries SIZE:Total Size: 59x35x15mm/2.3x1.4x0.6inch(L*W*H); Pin size:12x6.3mm/0.5x0.25inch(L*W);Pin center distance:17mm/0.7inch;Thread diameter: 10.5mm/0.4inch; Button Color:Black; Rated Current:30A; Input Power:125/250V AC, 50V DC 50/60Hz; Terminal Type:Plug terminal; Reset Method:Manual;2 Pcs of Circuit Breaker Kit(1pcs: 1xoverload protector,1xnut,1xidentification plate) FEATURE:DC circuit breakers use wear-resistant materials to ensure long service life, durable and reliable use, heat resistance, melting resistance and good conductivity, thermoplastic shell has high mechanical properties, good insulation, compact design can achieve high-density circuit protection configuration, good metal parts are stainless steel, which can maintain stable current connection and excellent thermal sensors. FUNCTION:Circuit overload protectors can play the role of over current protection and short circuit protection, protecting the power circuit from overheating due to overload.The manual reset design allows feedback after a period of disconnection. The reset button of the switch automatically cuts off the circuit when the load exceeds the rated current, effectively protecting the circuit. NOTE:Please pay attention to choosing an push-to-reset thermal overload protector with suitable rated current and voltage APPLICATION:
Circuit overload protectors can play the role of over current protection and short circuit protection, protecting the power circuit from overheating due to overload. Circuit breakers are widely used in household and commercial appliances, small generators, air compressors, automobiles, electric vehicles, power tools, extension cords, transportation, ships, telecommunications, power strips, audio-visual and power supply, industrial and marine industries

ADVANTAGES:
DC circuit breakers use wear-resistant materials to ensure long service life, durable and reliable use, heat resistance, melting resistance and good conductivity, thermoplastic shell has high mechanical properties, good insulation, compact design can achieve high-density circuit protection configuration,good metal parts are stainless steel, which can maintain stable current connection and excellent thermal sensors. The manual reset design allows feedback after a period of disconnection. The reset button of the switch automatically cuts off the circuit when the load exceeds the rated current, effectively protecting the circuit.

PACKAGE CONTENT:
Manual Push Button Breaker
Total Size: 59x35x15mm/2.3x1.4x0.6inch(L*W*H); Pin size:12x6.3mm/0.5x0.25inch(L*W);Pin center distance:17mm/0.7inch;Thread diameter: 10.5mm/0.4inch
Button Color:Black
Rated Current:30A
Input Power:125/250V AC, 50V DC 50/60Hz
Terminal Type:Plug terminal
Reset Method:Manual
2 Pcs of Circuit Breaker Kit(1pcs: 1xoverload protector,1xnut,1xidentification plate)

NOTE:Please pay attention to choosing an push-to-reset thermal overload protector with suitable rated current and voltage
