DIN Rail Terminal Blocks International Connector DK10N Dinkle UL Screw Type 600V 60A 6-20AWG, Pack of 50 (Green)

DIN Rail Terminal Blocks International Connector DK10N Dinkle UL Screw Type 600V 60A 6-20AWG, Pack of 50 (Green)

UL 600V UL 6-20AWG UL 60A Dinkle DK10N has a compact design that saves wiring space. The high reliability and robust design adapts vibration and harsh thermal variation to prevent terminal connection fault. Rated voltage: UL 600V, IEC 1,000 V. Rated current: UL 60A, IEC 57A. Conductor cross-section, solid(AWG/mm2): UL 22-6, IEC 0.5-10. Conductor cross-section, flexible(AWG/mm2): UL 22-16, IEC 0.5-10. Rated impulse withstand voltage: 8KV. Torque(N-m): 3.4. Screw: M5. Wire strip length: 14-16mm. Insulating material: PA. TxHxW(mm): 12 x 50 x 48.3. Accessory part numbers (not included): Jumper DSS10N-02P, DSS10N-05P, DSS10N-10P. End Cover DK10NC-GN. Marking label TM50W.
