WOODGUILIN Y Solar Connector 1 to 2 Solar Y Branch Parallel Cable,Solar Male Female Connector Adapter,4 mm² Cable Waterproof IP68, for Solar Panels,

WOODGUILIN Y Solar Connector 1 to 2 Solar Y Branch Parallel Cable,Solar Male Female Connector Adapter,4 mm² Cable Waterproof IP68, for Solar Panels,

【Y solar branch connector】: 1 male to 2 female (M/FF) and 1 female to 2 male (F/MM) (1 pair，red+black). Allows you to quickly connect 2 solar panel branches in parallel 【Specifications of Y Solar Connector】:Solar connector cable wire gauge 4mm², full length of connector: 20cm. Rated current: 30A, rated voltage: DC1000V 【Wide Application】：The Y solar plug connector is compatible with all kinds of solar cables. Adopting photovoltaic double-layer plastic plus copper core wire, anti-oxidation, anti-UV, high temperature resistance 【Waterproof performance】：Waterproof class IP68, plug with waterproof ring, waterproof and dustproof. Can be used in outdoor environment 【Plug and Play】:Can be installed quickly and easily with the solar Y connector. Disconnecting is simply by pressing the built-in latch on the connector. Easy, fast and safe connection 【Included Package】: 1 pair of Y solar connector 1 to 2 branches (M/FF&F/MM，red+black) 【Tip】: Due to long distance transportation plug nut will be loose. Please check the looseness when you receive the goods, if so please tighten it by yourself before use!

Widely used: 1 to 2 solar Y branch connectors are suitable for parallel connection of 2 solar modules. Widely used in solar power plants, rooftop systems, boats, street lights, mobile homes.

Safety: High load capacity with a rated current of 30A. Maximum load 35A, safer and more reliable.

Convenience: the Y branch cable is long enough to facilitate the connection. Plug and play, easy to connect and disconnect, not easy to disconnect.

Wide Compatibility: the Y type solar cable connector is suitable for most solar plugs on the market, and is compatible with solar cables from 14-10AWG.

Product Specifications：

Product name: Y shaped solar branch connector.

Product type: 1 male to 2 female (M/FF) and 1 female to 2 male (F/MM).

Connector length: 20 CM

Wire gauge: 4mm²

Insulating material: PVC

Rated current: 30 A

Rated voltage: DC 1000V

Temperature range: -40°C~120°C

Waterproof rating: IP 68

Contact resistance: ≤ 2.0mΩ

Fire protection class: UL 94-V0

Safety class: Class II

Scope of supply:

1 pair of Y solar connector 1 to 2 branches (M/FF&F/MM, red+black)

please make sure it is compatible with your device when you purchase.

Please contact us directly if you have any questions.
