AOHUA 4-Pack Q20 IP68 Waterproof 3-Pin Connector - Quick Docking 300V/15A Male/Female Electric Plug Socket for 5.5-10mm Cables, Industrial/Aviation

AOHUA 4-Pack Q20 IP68 Waterproof 3-Pin Connector - Quick Docking 300V/15A Male/Female Electric Plug Socket for 5.5-10mm Cables, Industrial/Aviation

✅🔌【4 sets of Q20-3 Pin waterproof connectors】Self-locking 3-pin waterproof wire connectors for outdoor use, each pack includes 4 sets with 2 sizes of grommets (5.5-10mm) to fit various cables. Male/female plugs with self-locking designs for LED billboards, garden lighting, and outdoor electrical setups. ✅🔌【Specifications】 Cable Diameter: 5.5-10mm (two grommet sizes included) Voltage/Current: AC/DC ≤300V, ≤15A (suitable for standard electrical loads) Temperature Range: -40°C to 105°C Waterproof Rating: IP67 (dustproof and water-resistant) Materials: Nylon shell with silicone seal, CE/ROHS certified. Colour:Black ✅🔌【Certification】This waterproof led connector has CE & IP68 & ROHS certificatesfor electrical safety.Nylon shell with silicone seal resists corrosion and UV damagePerfect for 3 pin connector needs in marine, automotive, and industrial environments Note:The 3 pin connector is waterproof and dustproof.If you use a cable which is too thin, then the seal won't even cover IP67! ✅🔌【Tool-Free Install】: Insert cable into female/male socket plug. Push to lock—automatic self-locking mechanism secures connection. Tighten cap for full IP67 protection No tools needed, ideal for trailer plug pigtail installations and on-the-go repairs. ✅🔌【Application】Fast release electrical barrel connectors are suitable for quick connection of Full scenario application. Commercial: LED streetlights, tunnel lighting, floor heating. Industrial: Machinery, power distribution, control panels. Aviation/RV: Onboard electrical systems, avionics. Medical/Communications: Equipment requiring secure, waterproof connections. Household applications: Garden fountains, pool pumps, outdoor sockets Backed by AOHUA’s 12-month warranty for peace of mind.

*Wire Connector : Q20-3Pin waterproof connector

*Cable range : 5.0-7.5mm/7.5-9.5mm ,suit for most usually power cord

*Pack of 4 piece.

*Cable Diameter Range: Ф5.0-Ф7.5mm/7.5-9.5mm;

*Rated voltage: ≤ 300V ;

*Rated current: ≤ 15A ;

*Working Temperature: -40°C~105°C ;

*Waterproof rating: IP68 ;

*Material: plastic (nylon), seal ring (silicon) ;

*Colour: Black & Blue*Certification: CE & IP68 & ROHS.

*Connection Method: The Srew-Assembly plug is easy to install, male and female can be separated and easy to install.

*Scope of Application: connectors are suitable for quick connection of garden and outdoor displays, floor heating, beacons, cruise ships, LED billboards, LED tunnel lights, LED street lights, external wiring, etc.

*USEAGE: Twist the port of the waterproof connector, insert the wire directly, soldering with electric soldering iron to secure the wire, and then close the cap.Please make sure connect the wire correct.

*Note: when finished, check that all nuts are tight. Inserted to panel from outside and screwed from inside.
