FOWIUNYE M8 6 Pins Male to Female Connector, A Code Straight Molding Female to Male Aviation Sensor Electrical PVC Unshielded Cable 30V 1.5A AC/DC

FOWIUNYE M8 6 Pins Male to Female Connector, A Code Straight Molding Female to Male Aviation Sensor Electrical PVC Unshielded Cable 30V 1.5A AC/DC

[M8 Connector Cable]: A coding interface, 6 Pin, Male to Female, Straight, 5M, AWG22, PVC Unshielded Cable, Connector contacts: Brass with gold plated, Cable specifications: 6 x 0.14 mm2, Solder Type [Technical Parameter]: IP Rating: IP67; Rated voltage: 30V, Rated current: 1.5A, Locking method: threaded type, Temperature range: -25°C to 85°C [Easy to Connect]: M8 cable provide quick and easy connection between field devices and terminal connections, flexible and convenient plug-and-play; No tools required for installation and removal [Data and Signal Transmission]: Thread joint is durable, while ensuring the stability and reliability of data and signals; M8 6 Pins male to female connector cable insulation and flame retardant; Thread locking mechanism, anti vibration locking design [Wide Used]: A code sensor plug cable is widely used in signal electronic connector of aviation, electric bicycles;6 pin aviation connector cable can be easily connected to sensor devices and ctuator devices and field bus components

Specifications:

Series: M8 6 Pin Connector Cable

Shield: Unshielded

Connection method: pre injected cable

Coding: A Coding

Termination Style: Screw-Joint

Rated voltage: 30V

Rated current: 1.5A

Temperature range: -25°C to 85°C

Protection Class: IP67

Connector contacts: Brass with gold plated

Housing material: PA6

Packing List:

1 Pcs x M8 6Pin Male to Female Industrial Cable

Notice: FOWIUNYE is a professional connector manufacturer specializing in the production of M8, M12, and other related products. The coding types include A, B, D types, male and female connectors, PVC wire, PUR, and cable lengths can be customized, including 3, 4, 5, and 8 pins; If you need anything, please feel free to contact us at any time
