UHPPOTE Proximity 125KHz RFID Card Reader Wiegand 26 bit or Wiegand 34 bit for Door Access Control System

UHPPOTE Proximity 125KHz RFID Card Reader Wiegand 26 bit or Wiegand 34 bit for Door Access Control System

✅ The RFID card reader can't work-alone and it needs to work with Wiegand protocol access controller, such as access control panel, fingerprint device or master controller. ✅ Built-in buzzer & double color LED to show the status. ✅ Waterproof: Conforms to IP66, can be Installed outside. ✅ This device uses high performance MCU to ensure stable performance, and low-power circuit makes the service life longer. ✅ Widely used in factories, houses, residential quarters, offices, mechanical and electrical control equipment and so on.

Features:
The maximum reading distance is 6cm.
Waterproof, conforms to IP66.
It is useful for safety door system, easy to connect and use.
Ultra-low power consumption, the standby current is less than 50mA.
Support wiegand 26bits or wiegand 34bits output format.
Fast response speed, the door opening time is less than 0.3s.
This device uses high performance MCU to ensure stable performance, and low-power circuit makes the service life longer.
Widely used in factories, houses, residential quarters, offices, mechanical and electrical control equipment and so on.
The RFID card reader can't work-alone and it needs to work with Wiegand protocol access controller, such as access control panel, fingerprint device or master controller.

Specifications:
Working Voltage: 12VDC
Static Current: ≤50mA
Card Type: Standard EMID
Frequency: 125KHz
Working Temperature: -40 to +140°F
Working Humidity: 10%-90%RH
Output Format: Wiegand 26bits or Wiegand 34bits (Selectable)
Waterproof Rating: IP66
Enclosure Material: ABS Plastic
Panel Material: PC
Shell Size: 110.8x71.8x22.2mm / 4-21/64"x2-51/64"x29/32"
Communication Distance: Less than 100m / 328ft
Lead Cable Length: 25cm / 9-27/32"
Status Indication: Bi-color LED + Buzzer
Wiegand Output: Wiegand 26 bit or Wiegand 34 bit (Selectable)
LED Status Indication: Red means standby, Green means activated

Package:
1 x Card Reader
1 x User Manual
4 x Plastic Anchors
4 x #7 x 1" Self-Tapping Screw, used for fixing
