CNCTOPBAOS 3020 Plus CNC Router for Wood Milling,GRBL Control 500W Spindle Metal Engraving Machine w/Touchscreen Offline Controller,Limit Switches,

CNCTOPBAOS 3020 Plus CNC Router for Wood Milling,GRBL Control 500W Spindle Metal Engraving Machine w/Touchscreen Offline Controller,Limit Switches,

Larger Work Area: Working area is 300x200x73 mm 11.81x7.9x2.9 inch; Overall Size: 460x390x354 mm 18.1x15.4x13.9 inch; The worktable has an accurate scale line,which is convenient to locate and measure the size of the engraving material.The machine is equipped with an emergency stop and six limit switches Touchscreen Offline Controller: This offline controller is equipped with a 2.8 inch LCD touch screen,it can make controlling the engraving machine more simple and convenient; Product Size: 95x80x18.5 mm 3.74x3.14x0.72 inch; You can successfully and easily operate the engraving machine without connecting to a computer,greatly improving work efficiency;Just put the project you need inside that SD card,and you can operate the engraving machine via this offline controller All Metal Body: The body structure of this 3020 Plus CNC engraving machine is made of All-Metal no plastic parts;It is equipped with 12 mm thick solid double-steel linear guide rail and bearing slide rail; All-metal X-Z axis parts have a vertical stroke of up to 73 mm,these designs enable the machine to move faster,with 0.01 mm high accuracy and stability 500W ER11 Spindle: The 3020 Plus CNC router is equipped with 500 W 48 V 11000 rpm spindle with ER11 collet,which is more powerful and efficient,can cut copper,aluminum and other metals; Supported Software&Systems: CNC engraving machine is compatible with GRBL software/Candle and supports Windows XP/7/8/10 and Linux; The device has been pre-assembled and can be simply assembled after unpacking Wide Application: Can engrave on Wood, MDF, Carbon fiber, PCB, PVC, Leather, Paper, Acrylic, Ceramic products, Food, Bamboo, Plastic, Plywood, Stainless steel, Brass, Plexiglass, Aluminum and so on.This machine can both carve and cut.It can cut 8 mm wood products at one time,more easy to create DIY handmade.If it is aluminum material,repeat the path multiple times to carve, and the depth can reach 10 mm

Package include:

1x 3020 Plus cnc router engraving machine

1 x Touchscreen Offline controller with cable with SD card

1x 500W DC spindle

1x Emergency Stop

6x limit switches board (XYZ both ends)

1x Z Axis Probe tool

1 x GRBL control board

1 x 10Pcs Engraving bits

1 x 2G U disk with GRBL software

1 x English User Manual

Advantages

The body structure of this 3020 Plus CNC engraving machine is made of All-Metal(no plastic parts).

It is equipped with 12mm thick solid double-steel linear guide rail and bearing slide rail.

All-metal X-Z axis parts have a vertical stroke of up to 73mm,these designs enable the machine to move faster,with 0.01mm high accuracy and stability.

The worktable has an accurate scale line,which is convenient to locate and measure the size of the engraving material.

The machine is equipped with an emergency stop and limit switches.

The 3020 Plus CNC router is equipped with 500W 48V 11000rpm spindle(with E11 collet),which is more powerful and efficient,and can cut stainless steel,aluminum and other metals.

Small and practical, no problem for using on your desk.

Support Win XP, Win 7,Win 8, Win 10 system

Aluminum alloy material with fine workmanship show excellence in quality.

Very interesting to install and use, perfect gift for engraving DIY enthusiasts.

Wide application: can be used for print, hand tools and industrial processing.

Parameter

Overall size: 46×39×35.4cm (18.1×15.4×13.9inch)

Engraving area: 300x200x70mm (11.81×7.9×2.9inch)

Construction: Aluminum

Control Software: GRBL Control (Candle)

Spindle Motor: 500w Spindle DC48V, Max.11000rpm/min

Stepper Motor: Nema17 stepper motor 1.68A 0.55N.m

Power Supply: Output DC48V 10.4A

Precision: 0.01mm
