DC 12V 16 Channel PLC Expansion Board，Din35 C45 DIN Rail RS485 Relay Modbus RTU Protocol Remote Control PLC Expansion Board for PTZ Camera Motor Led (

DC 12V 16 Channel PLC Expansion Board，Din35 C45 DIN Rail RS485 Relay Modbus RTU Protocol Remote Control PLC Expansion Board for PTZ Camera Motor Led (

"Standby current (all relays closed) 12MA, 1 relay open 41MA, 2 relays open 69MA, 3 relays open 95MA,4 relays open 122MA,5 relays open 148MA,6 relays open 174MA, 7 relays open 198MA,8 relays open 225MA.etc " ''Open'' ''close'' ''Momentary'' ''Self-locking'' ''Interlock'' ''Delay'' 6 Commands Two instruction-control mode : MODBUS RTU command and AT command Under the ''Delay'' command ,the maximum delay is 255 seconds; Under the AT command ,the maximum delay is 9999 seconds Specification:
DC 12V power supply
Standby current (all relays closed) 12MA, 1 relay open 41MA, 2 relays open 69MA, 3 relays open 95MA,4 relays open 122MA,5 relays open 148MA,6 relays open 174MA, 7 relays open 198MA,8 relays open 225MA.etc
''Open'' ''close'' ''Momentary'' ''Self-locking'' ''Interlock'' ''Delay'' 6 Commands
Two instruction-control mode : MODBUS RTU command and AT command
Under the ''Delay'' command ,the maximum delay is 255 seconds;
Under the AT command ,the maximum delay is 9999 seconds
MODBUS commands can be made serial HyperTerminal (serial assistant) OR ''Modbus Poll'' Enter; AT commands can be made serial HyperTerminal (serial assistant) Enter;
Under the MODBUS command mode, it can support up to 64 devices in parallel
The default baud rate is 9600BPS. The baud rate can be selected through jumpers: 2400 4800 9600 19200BPS
Size: 180*72*20mm(Only PCB Board);184*88*42mm(with Din Rail Box)
10 Weight: 230g(Only PCB Board);358g(with Din Rail Box)
11 Maximum load: 10A / 250VAC, 10A / 125VAC, 10A / 30VDC, 10A / 28VDC, 10A / 12VDC
DIN rail Box parameters:
Product model: UM72
Color: green
Width: suitable for PCB board width UM72(72mm)
Insulation grade: flame-retardant VO grade
Backplane length: suitable for 180 mm PCB boards
Net weight: 128g
Installation: DIN35 and C45 ra
Note:
1.Due to the light and screen difference, the item's color may be slightly different from the pictures.
2.Please allow 1-3cm differences due to manual measurement.
1x Relay Module
