jamgoer 300A Bus Bar 12v Power Distribution Block 4 x 5/16"(M8) Terminal Block Heavy Duty Waterproof Buss Bar Junction Block Marine Battery Bus bar

jamgoer 300A Bus Bar 12v Power Distribution Block 4 x 5/16"(M8) Terminal Block Heavy Duty Waterproof Buss Bar Junction Block Marine Battery Bus bar

Versatile Compatibility: Our Bus Bar is ideal for automotive, marine, and solar applications, compatible with 12V, 24V, and 48V DC power systems; It boasts a maximum continuous current of 300 A; Size of each power distribution block is 138 x 69 x 44.5 mm; Stud size: M8 (5/16") Premium Quality Materials: Crafted from high-quality copper, each distribution block ensures excellent conductivity and durability and can work stably for a long time Safety & Reliability: Our bus bars undergo rigorous quality testing to ensure safety, reliability, and long-term stability; Featuring a protective cover to shield against water and dust, preventing damage and corrosion; The base is made of flame-retardant nylon fiberglass to enhance safety for both equipment and personnel Easy Installation: The bus bars are secured with simple screw fastening, enabling easy installation and disassembly; Removable windows ensure smooth access for wiring without obstructions, facilitating maintenance and management Wide Application: The Heavy Duty Power Distribution Block makes the wiring of circuit become neat and tidy and prevent electric short circuit, suitable for automotive, car, truck, marine, boat, RV, Solar, etc Specification:

•Base & Cover Material: Glass Fiber reinforced Nylon
•Bus Material: Brass, Nickel plated
•Working voltage: DC 12V - 48V
•Max Operating Voltage: DC 48V
•Max Continuous Currents: 300A
•Terminal Stud Size: 4x M8（5/16"）
•Dimensions (L x W x H): 138 x 69 x 44.5mm, (5.433"x2.72"x1.75")
•Weight: 12.8 ounce/pcs

Including:

•1 x Red Heavy-Duty Busbar Box
•1 x Black Heavy-Duty Busbar Box
•Already assembled, don't worry
