NEWTRY 1320lb Electric Hoist Lift, Wireless & Cable Remote Control Overhead Electric Winch Pulley System, Single & Double Slings for Garage, Ceiling,

NEWTRY 1320lb Electric Hoist Lift, Wireless & Cable Remote Control Overhead Electric Winch Pulley System, Single & Double Slings for Garage, Ceiling,

[TWO CONTROL METHODS]----Provides wired & wireless control methods, allowing you to control your electric hoist from a distance without standing under heavy objects. Wired remote control, with a control line length of 6.5ft/2m, simple to use; 330ft/100m control range, wireless remote control can be used from anywhere within range, making them ideal for larger rooms or spaces. [EASY OPERATION]----Come with a pulley hook for double-line operation, which increases the load capacity. Single line load: 660lb, 32.8 ft/min, max lifting height: 40 ft; Dual line load: 1320lb, 16.4 ft/min, max lifting height: 20 ft [SAFETY]----Equipped with a limit switch, when rising close to the limit position, the electric hoist will automatically cut off the power to effectively protect itself, while ensuring that the wire rope position does not deviate during use. [HOW TO INSTALL]----The overhead crane needs a metal bar or solid wood bar to provide enough weight to hang/fix the hoist to the ceiling indoors. The installation method can be referred to Figure 5. [WIDELY APPLICAITON]----The power electric hoist can be used to lift regular or irregular items such as lawn mowers, engines, stones, trees, etc. Our electric hoist can be placed in garages, ceilings, attics, barns, and attics.

Parameter:

PA600 Small Electric Hoist

Load Capacity: 300|600kg

Lifting Height: 6|12m

Voltage: 110V-60Hz

Input Power: 1200W

Insulating Grade: B

Work Rate: 20%  10min

Protecting Grade: IP40

Lifting Speed: 5m/min | 10m/min

Control Method

Pendant/Wire Control

With a control line length of 6.5ft/2m. Wired connection, with the interface on the receiver.

Wireless Remote Control

Control range: 100m/330ft. The remote control is connected to a receiver on the machine to control the machine's ascent and descent.

Re-paired Method of Wireless Remote Control

1. Plug off the receiver power supply

2. Press and hold the" STOP "and" DOWN "keys at the same time, and the indicator light on the remote control will alternately flash with red/greed lights.

3. Plug in the receiver power supply
