EPLZON 300A Resettable Circuit Breaker - 300 Amp Self Recovery for Car Audio & Amps Protection

EPLZON 300A Resettable Circuit Breaker - 300 Amp Self Recovery for Car Audio & Amps Protection

Features: Large current thermal trip circuit breaker with manual reset switch, suitable for auxiliary DC electrical system, when the current reaches a predetermined value, the fuse can be restored to automatically disconnect and protect the circuit Circuit protection function: When the current reaches a predetermined value, the recoverable fuse will automatically disconnect to protect the circuit. Prevent excessive current and protect electrical appliances. Overcurrent protection, overvoltage protection, residual current protection, overcharge protection. Simple installation: No need to replace the built-in fuse, and it can also be used as an on/off button battery switch. The circuit breaker has simple installation steps and can be installed on any flat panel, or on the wall or in the car. Material and wiring: The shell and parts are made of highly flame-retardant and anti-vibration plastics, with a long service life. It accepts 0/2/4/8 specification power cords with adapters for direct connection with all 12, 24 volt systems Application: Provide protection for overload or short-circuit current when using high current electricity such as automobiles, ships, ships, RVs, caravans, tractors, loudspeakers, horns, automobile dual-battery isolators, and winches. Audio circuit breakers, Large current thermal trip circuit breaker with manual reset switch, suitable for auxiliary DC electrical system. EPLZON 300A Circuit Breaker Resettable Circuit Breaker Self-recovery Fuse Manual Reset Button for Car Audio and Amps Protection

Specification:

Current: 300A
Voltage: 12-24V DC
Dimensions: 2.63 inch (length) x 1.96 inch (width) x 1.37 inch (height)
Material: plastic and metal
Color: black shell + gray cover
Weight: about 204g/7.2oz
Number of poles: 2
Features: manual reset
Suitable wire gauge: 0、2、4、8 AWG
Operating temperature: -10℃ to 50℃ (-14℉ to 122℉)
Current load VS time trip: 100%VS 20-180s; 150% VS 6-40s; 200% 4-25s

Circuit breakers can be used to distribute power, start asynchronous motors infrequently, and protect power lines and motors.
Prevent electrical surges from damaging your amplifier and protect your motors from electrical damage.
The unique button reset installed on the panel or firewall can also be used as a kill switch.

application:

Suitable for overload protection of car audio/video systems, boats, trucks, buses, RVs, ATV winches and marine and DC sound amplifier systems.

Package Included:

1x 300A circuit breaker car audio inline fuse

Please note:

Please press the button correctly to avoid damage to the circuit breaker.
Please confirm the working temperature before purchasing to avoid stopping work due to high temperature.
