SSK Aluminum M.2 NVME SATA SSD Enclosure Adapter, Tool-Free External SSD Reader USB C 3.1/3.2 Gen 2 10Gbps PCIe, 6Gbps SATA M Key B+M Key M.2

SSK Aluminum M.2 NVME SATA SSD Enclosure Adapter, Tool-Free External SSD Reader USB C 3.1/3.2 Gen 2 10Gbps PCIe, 6Gbps SATA M Key B+M Key M.2

Applicable SSD: SSK M.2 NVME SATA SSD Enclosure is compatible with both SATA and NVME PCIe M Key and B+M connectors SSD for sizes: 2230/2242/2260/2280. It is not compatible with B Key Connectors. It does not support M.2 PCIe AHCI SSDs, M.2 PCIe devices such as WiFi and capture cards, mSATA SSDs, and non-M.2 form factor SSDs. Compatible with M.2 NVMe/SATA PCIe M key,PCIe B&M key SSD. Note: NVMe and SATA SSD are not included. Aluminuam Alloy Shell: Adopts aluminum alloy shell, slim design, and excellent heat dissipation, be portable and easy to carry; Includes 2 x Thermal Pad，both USB Type-C and USB 3.0 (Type-A) cables. Tool-Free Design and Speed: 100% Tool-Free, quickly install and remove SSDs without any tools. M.2 NVME USB3.1 Gen2 Transfer speed is up to 10Gbps, M.2 SATA USB3.1 Gen 2 is up to 6Gbps. Thunderbolt 3 compatible. One HD movie transfer only takes 2 seconds; Backward compatible with USB3.1 Gen1 and USB3.0 at respective speed limits.Thunderbolt 3 compatible. Blue Indicator: Blue Indicator shows the data transfer status, easy and clear;SSD file system must be supported on host operating system to be accessible. As with all SSDs, new media must be formatted before use. Master Chip: Adopts high performance controller IC Chipset JMS581DL, Complies with UASP, Trim which can effectively improve the speed and extend the longevity of SSD. Plug-and-play, no additional drivers required. Bus powered, does not need an external power supply. Compatibile with Multi OS, Windows 7/ 8/ 8.1/ 10/ Linux/ MAC. Please take care to check if your SSD is M.2 PCIE NVME or M.2 PCIE SATA otherwise it will not work. Please let us know if you are not sure if it is the right one. We will do our best to help you.

Product Specifications :
Product name: M.2 NVME SATA SSD enclosure adapter Tool-Free
Interface type: M.2 NVME NGFF USB 3.1
Transfer Rate : Up to 10Gbps
Case Size: 114*38*12mm
Material: Aluminum alloy
Cable Type : Type C to Type-C
Cable Length: 150mm
Support SSD Drivers Size: 2230, 2242, 2260, 2280mm
Color: Grey

Features:
1. USB 3.1 Type-C extreme fast and high-capacity data transfer solution, Data transfer rate up to 10Gbps for USB 3.1;
2. Supports NVME PCIE-based M.2 SSD and SATA NGFF based SSD;
3. Easy installation & no driver required, No additional power required;
4. Supports Plug & Play and Hot-Swapping;
5. Multi OS Supported, like Windows, Mac OS & Linux etc.

Package Included:
1 x M.2 NVME NGFF USB 3.1 Type-C SSD Enclosure
1 x USB 3.1 Type-C to Type-C Cable
1 x Screw Set

Please note that it supports NVME and SATA NGFF SSD(Double protocol).
We tested our enclosure with Sumsung 970 EVO NVMe SSD, the actual speed can reach to 1000MB/s on R/W. But to this speed, pls make sure the Laptop TYPE C port is also comply with USB3.1 Gen 2(10Gbps), if USB3.1 Gen 1(5Gbps), then speed will be only half.
For the brand new SSD drive, it may not be found, so please format it before the first time using. Pls format it to corresponding type which Windows and Mac supported.

Follow step is to find the brand new ssd drive:
1. Use your mouse right key to click "Computer", it will show a drop-down menu;
2. Use your mouse left key to click "Computer Managment";
3. Use your mouse left key to click "Disk Management”;
4. After find the brand new ssd drive, please format it, and made partition. Then you can find the drive normally.
