avedio links 196ft/60m HDMI Extender Over Cat 5e/6/7, 1080P HDMI Ethernet Extender Balun Adapter with Single POC Power Supply, Support 3D, EDID, Deep

avedio links 196ft/60m HDMI Extender Over Cat 5e/6/7, 1080P HDMI Ethernet Extender Balun Adapter with Single POC Power Supply, Support 3D, EDID, Deep

196ft HDMI Extender Balun: With a single high quality CAT5e/ 6/ 7 cable, you can extend HDMI audio / video signals simultaneously for up to 196ft by avedio links HDMI to Ethernet extender. NOTE: CAT5e Ethernet cable can only up to 165ft (50m). 1080P HDMI Extender Over Ethernet: Support 3D and deep color up to 36 bits, lossless compressed digital audio, and data transmission speed of 6.75Gbps. Which will bring you the best video/audio experience. RECOMMEND using HDMI to HDMI connection directly, avoid using signal converters or adapters! HDMI Extender With POC Power Supply: Adopt POC technology, power over cable, only one power adapter is needed to connect to the TX terminal can support the entire device's operation, more simple and convenient. No driver required, just plug and play. EDID Management: This 60m HDMI extender support EDID handling abilities, it can recognize the display device parameter and make it match to the equipment, which can get better compatibility. The sturdy metal shell makes more durability and minimize EMI/RFI noise interference. Wide Compatibility: avedio links HDMI extender's built-in automatic adjustment system can make the PC, DVD player, PS4, PS5, TV box etc more stable. Can be widely used in education, digital signage, churches, classrooms, meeting rooms, projects, games, video conference, metro, multimedia home theater etc.
✨avedio links HDMI-60M-Extender with POC Power Supply Over Cat 5e/6/7
--Features--
🔹 Each set includes one transmitter and one receiver.
🔹 DC 5V power supply. (We strongly recommend connecting to the TX):
If the power adapter is connected to the TX, the extender supports up to 60 meters of CAT6 cable.
If the power adapter is connected to the RX, the extender supports up to 30 meters of CAT6 cable.
🔹 Use single UTP LAN cable (Cat6) to substitute HDMI cable to achieve long distance transmission, the UTP Cable follows the standard of IEEE-568B.
🔹 Transmission distance extend up to 60 meters under 1080P.
🔹 Support Deep Color up to 36 bits.
🔹 Support lossless compressed digital audio: Dobly True HD, DTS-HD Master Audio.
🔹 Transmit Digital Audio and Video over the CAT6 cable with zero signal loss.
🔹 Data transfer speed 6.75Gbps.
--Connecting and Operating--
🔹 Connect the HDMI signal sources (Such as PS4/5, STB etc) to HDMI Transmitter.
🔹 Connect CAT6 cables to both the outputs of the transmitter and inputs of the Receiver. (The cables must follow the standard of EIA-TIA 568B).
🔹 Connect the HDMI output (Such as HD-LCD, HD-DLP) into the Receiver.
🔹 Please connect the 5V power supply to TX so that the signal can be transmitted longer.
--Package Contents--
1x HDMI-60M-EXTENDER TRANSMITTER + RECEIVER
1x 5V/1A DC POWER ADAPTOR
1x USER MANUAL
