DC Drive Motor with Flywheel 130VDC, 24.4 Amps 4.25 H.P, 5125 RPM, Powerful Treadmill Duty Motor for Smooth Operation Easy Replacement P/N 321628 & L-

DC Drive Motor with Flywheel 130VDC, 24.4 Amps 4.25 H.P, 5125 RPM, Powerful Treadmill Duty Motor for Smooth Operation Easy Replacement P/N 321628 & L-

Dynamic Performance: The H.F Exchange powerful DC motor (Part # 321628 & L-315219 & 116ZY1-1) operates at 130 volts (DC), 24.4 Amps, 5125 RPM, and 4.25 HP, offering variable speed options to suit your workout intensity. Its low noise operation enhances your overall experience, while its robust construction guarantees reliable and consistent performance over time. Compatible with Leading Brands: It is versatile for use in assembly motor applications, providing reliable and consistent performance thanks to its small DC motor design and powerful capabilities. This electric motor is easy to install and compatible with popular treadmill models from FreeMotion, Nordic-Track, and others. It seamlessly integrates with models such as the NETL247130, NTL240152, and VMTL298115. Effortless Fitness Mastery: Experience uninterrupted workouts with our powerful magnet DC motor and enjoy a comfortable exercise environment with H.F Exchange, ensuring your fitness sessions are both efficient and enjoyable. Whether you need an electric drive motor, DC drive motor, or replacement treadmill motor, our treadmill motor delivers exceptional performance for your fitness needs. Efficient Energy Transfer: Our high-power permanent magnet DC treadmill drive motor ensures smooth and stable rotational movement, thanks to its pure copper winding. The stator, an external component, provides a stationary magnetic field, while the armature, the motor's moving part, carries the current and rotates within this field, enabling precise control and high torque output. Expert Assistance: Need installation or maintenance? Find qualified technicians near you for seamless assembly and optimal functionality. Our experienced team can recommend a qualified fitness technician in your area based on your zip code, ensuring your motor operates at peak efficiency, whether it's for assembly, electric drive, or treadmill motor replacement.

Part #: 321628 & L-315219 & 116ZY1-1
Used on the following models:

Nordic-track
NETL247130
NETL247131
NTL240130
NTL240131
NTL240150
NTL240151
NTL240152

Freemotion
VMTL298110
VMTL298111
VMTL298113
VMTL298114
VMTL298115
VMTL298116
VMTL298117

SPECIFICATIONS

• Power 4.25 HP (3170 W)
• Voltage 130 VDC
• Amperage 24.4 Amps
• Speed 5195 RPM @ 130 VDC, No Load
• Rotation Reversible
• Enclosure OFC
• Duty Treadmill
• Mount Two 5/16"-18 Threaded Holes in Housing on 3" Centers
• Shaft 17mm dia. x 42mm overall length, stepped down to 14mm dia. with 5mm keyway, End tapped 10-32
• Size 12-1/4" x 6-3/4" O.D.
• Shpg. 33 lbs.
