MAD M30 PRO IPE 100KV Drone Brushless Motor for Heavy Multirotor Quadcopter Hexrcopter RC DIY

MAD M30 PRO IPE 100KV Drone Brushless Motor for Heavy Multirotor Quadcopter Hexrcopter RC DIY

Heavy-class motor tailored for 12–15 kg single-axis payloads Built for industrial UAV platforms requiring extreme thrust and reliability This large drone brushless motor was designed for rigorous conditions and endurance flight, IP44 Peak thrust: 45.2 kgf | Rated thrust: 12–15 kgf Ultra-lightweight for its class: 1630g Supports 12S voltage systems Maximized thrust-to-weight ratio for heavy-lift, long-endurance flight

MAD M30 motors are the ultimate brushless motors specially designed for large-scale multi-rotor electric paraglider. Used for aerial photography, mapping, electrical paragliding, agricultural spraying, surveying or anything in between where professional industry level propulsion systems are required. This type of motor is made with industrial grade components and undergo intense testing and quality control. Waterproof and dustproof M30 motors deliver reliable high-quality performance that will handle all flying tasks.

M30 focuses on improving efficiency and thrust for your multirotor UAV.

The weight of this motor is only 1630g and MAD M30 100KV works perfectly with MAD AMPX 200A ESC and Fluxer36"- -40" carbon propeller. Such propulsion system can achieve maximum thrust of 49kgf/107 pounds

Specifications

motor model: MAD M30

KV value 100KV

configuration 36N30P

Rated voltage 12s

No load current 3.2A/10v

Internal resistence 17MΩ

Motor weight 1630g

Maximum current 195A

Product boxed weight 2100g

Max watt 14160W Max torque:22.25N.m Max thrust:49kg

Recommend propeller 36″-40″

Recommend ESC AMPX 200A-15S
