DC 12V 16 Channel MODBUS RTU RS485 Relay Module Board PLC Controller Serial Port Switch

DC 12V 16 Channel MODBUS RTU RS485 Relay Module Board PLC Controller Serial Port Switch

This relay module board's working voltage is DC 12V and standby current is11mA.Under the MODBUS command mode, this relay module can support up to 64 devices in parallel. MODBUS commands can be made serial HyperTerminal (serial assistant) or "Modbus Poll" enter,and MODBUS RTU command control mode, the maximum delay is 255 seconds. MODBUS command mode (HEX), you can control a variety of ways: Serial Hyper Terminal Control (need to manually add the CRC), Modbus Poll software control (software automatically add the CRC), PLC or MCU process control. This relay module has 6 commands: "Open", "close", "Momentary", "Self-locking", "Interlock" and "Delay". We strive to provide you with the highest quality product and the best customer experience, if you're not entirely satisfied, please just feel to us at any time.

Specification:
Working Voltage: DC 12V
Standby Current: 11MA
Load: 10A/250VAC, 10A/125VAC, 10A/30VDC, 10A/28VDC, 10A/12VDC
Size: Approx. 17*6.5*2cm / 6.7*2.5*0.8in
Weight: Approx. 224g/7.9oz

Typical applications:
MODBUS command mode (HEX), you can control a variety of ways: Serial Hyper Terminal Control (need to manually add the CRC), Modbus Poll software control (software automatically add the CRC), PLC or MCU process control.

WIring DIagram:
1. DC 12V control circuit,Wiring diagram below. "LOAD" may be camera,LED lights, fans, motors and other DC 12V equipment.
2. DC 1-100V or AC 85-265V control circuit,Wiring diagram below(Note:If not DC 12V load, need another DC 12V power supply). "LOAD" may be LED lights, fans, motors Lights, fluorescent lights, solar water heaters and other DC AC equipment.

Package list:
1 * 16 Channel RS485 Relay
