CNLINKO 2Pin Male Female Plug Socket Industrial Waterproof Power Connector, M16 10A Cable Circular din Connector, IP68 Connector Blind Mate Power

CNLINKO 2Pin Male Female Plug Socket Industrial Waterproof Power Connector, M16 10A Cable Circular din Connector, IP68 Connector Blind Mate Power

LP16 2-Pin Connector Overview: This male plug and four-hole socket combination are designed for plug/unplug connections with an IP68 waterproof protection rating (when mated), ensuring excellent dust and water resistance. Cable Specification:Designed to fit cables with a size range of 1.0-1.5mm² (18-16 AWG), and a cable diameter of Φ7.0~Φ9.0mm, making it suitable for various industrial and commercial uses. The contact diameter is Φ1.5x2. The connector is designed for over 500 cycles at temperatures ranging from -25°C to 85°C. Electrical Specifications: Rated for 10A current and 400V AC operating voltage. With a withstand voltage of 2000V for 1 minute, contact resistance under 3.0mΩ, and insulation resistance over 500MΩ, ensuring reliable and stable electrical performance. Note: Avoid charging during insertion. Materials: Constructed with high-performance engineering plastic for the shell, zinc alloy (pearl hard chromium) for metal components, and gold-plated copper alloy for the contacts. Silica gel sealing provides superior protection against moisture, dust, and corrosion, ensuring long-term durability. Industrial & Professional Applications: Commonly used in applications like medical equipment, solar energy systems, vehicle electronics, communication devices, and other industrial equipment, providing versatile solutions for professional needs. Connecting mode: Latching Lock connect
Protection level: IP65/IP67
Cable specification: 18-16AVG Diameter range: Φ3mm~Φ9mm
Contact diameter×Qty: Φ1.0×1.5mm²
Current rating(A): 10A
Operating voltage(AC.V.rms): 400V
Withstand voltage(AC.V)1min: 2500V
Contact resistance: 500MΩ
Durability: ≥500 mating&unmating cycles
Temperature rating: -40°C~80°C
Method of connecting cable: Solder
Prevent the combustion level: UL94-V0
Material
Shell&insulated parts: High performance engineering plastics
Hardware metal: Zinc alloy(pearl hard chromium)
Contact pin: Copper alloy(gold-plated)
Spring: Stainless steel
Sealing: Silica gel
