DECFLO-110V High Pressure Self Priming Water Diaphragm Pump,5LPM/80GPM 160PSI Water Pressure Booster Pump Sprayer for Home/Misting/Caravan/RV/Boat/

DECFLO-110V High Pressure Self Priming Water Diaphragm Pump,5LPM/80GPM 160PSI Water Pressure Booster Pump Sprayer for Home/Misting/Caravan/RV/Boat/

1.Technical Parameters: Max Shut off Pressure-160PSI, Max Open Flow-5LPM /80GPH, Voltage-110V/0.55AMP, Maximum head-95m. 2. Self-priming 6 Feet: Allows for usage even if located above water tank. Positive displacement diaphragm pump, capable of being run dry. 3. High Quality : 100% full copper wire high-quality motor,long service life, no leakage, quiet operation. Changeable pressure switch. Spare parts supported. 4. Double Protection: Sealed pressure switch automatically turns the pump off when pressure builds up.Built-in thermal protector. Due to overload thermal overload protection auto stops and re-start motor. 5.Application:Marine yachts,RVs,automobiles,boats,vans,household,industry, agriculture ,catering services,distillation equipment etc. Product Description

Specification:
Voltage:AC110V /0.55AMP
Max Shut off Pressure:160PSI
Max Open Flow:5LPM /80GPH
Max Liquid Temp: 140℉(60℃)
Maximum lift: 95m
Weight:2.7kg
Interface aperture: 12.7mm
Valve material: EPDM
Diaphragm material: Rubber elastic material
Protection Valve Type: intelligent valve （with Pressure switch）
Medium:no oil, no strong corrosive, non-acid and alkali, no solid particles

Package includes:
◆Water diaphragm pump
◆1/2"Pagoda-Type straight joint×2
◆1/2"Thread-Type straight joint×2

Features:
-Runs dry without damage.
-Numerous fittings options for greater mounting flexibility.
-Overload and overheating double protection system.
-Light and small,low noise,high flow,sturdy base, energy efficient,steady operation.
-Application:marine yachts, RVs, automobiles,household,industry, agricultural misting etc.

Note:
▲Please clean it regularly in case of debris blockage.
▲Provide appropriate pressure adjustment to the switch.
▲Factory set pressure value for daily use is 125PSI. If needed, it can be adjusted to 160PSI.
▲If the pump shakes or vibrates at a high rate of frequency, please adjust the tap to discharge more water.
▲Never use a high pressure for your flow pump to fit a thin sprayer. Can not dry for extended periods of time.
▲Intermittent work. Built-in thermal protector.A single continuous work 60-90 minutes, cooling 15-20 minutes to work again.
▲Improve pressure may cause server overload or vibration. Keep the pressure value not too low, otherwise the device will start and stop frequently, which will cause motor damage.
▲Long time operation at small flow/leakage would damage pressure switch very quickly. Choose the correct pump according to system flow and pressure when you use it for same application.
