uxcell 10Pcs 150K Ohm Resistor, 5W 5% Tolerance Metal Oxide Film Resistors, Axial Lead, Flame Proof for DIY Electronic Projects and Experiments

uxcell 10Pcs 150K Ohm Resistor, 5W 5% Tolerance Metal Oxide Film Resistors, Axial Lead, Flame Proof for DIY Electronic Projects and Experiments

150K Ohm, +/-5% Tolerance, 10 pieces in total 5 watt metal film resistor with high accuracy of +/-5% (J) Four bands standard EIA color code Typical axial-lead with low noise and high performance Noted: Different Resistance on this listing, please check what you need correctly before purchasing. Features:


Metal oxide film resistors exceed the performance of metal film and carbon film for the following properties: power rating, voltage rating, overload capabilities, surges and high temperatures.
The metal oxide film resistors have 5% tolerance. The temperature coefficient is around -55℃～155℃.
The resistance material for metal oxide resistors is tin oxide that is contaminated with oxide, this is to increase the resistivity. Metal oxide resistors can withstand higher temperatures than carbon or metal film resistors.
Noted:Different Resistance on this listing, please check what you need correctly before purchasing.


Specification：


Rated Power:5 W;
Maximum working voltage:500V;
Maximum overload voltage:1000V;
Maximum pulse voltage:1500V;
Dielectric withstanding voltage:700V
Operating temperature range:-55℃～155℃;
Resistance Values (Ohm):150K;
Resistance Tolerance (%):5%;
Packaging:Axial;
Body Size:24.5+/-2.0 mm x 8.0+/-1.0 mm（LxD)
Total Length:86.5+/-5.0mm;
Lead Wire Size:31+/-5mm x 0.7+/-0.1mm(LxD)


Package Content：


10 Pcs x Metal Oxide Film Resistor
