Beduan Brass BPL Push to Connect Air Fittings Elbow 3/8" Tube OD x 1/2" NPT Male 90° Degree Adapter

Beduan Brass BPL Push to Connect Air Fittings Elbow 3/8" Tube OD x 1/2" NPT Male 90° Degree Adapter

Type:Push in fitting/Push to connect /Size:3/8 " Tube OD x 1/2" NPT Thread Fluid Admitted:Air Vacuum Water (no freezing) Working Pressure:0-1.0MPa | 0-150psi/Applicable Tube:PU / PA / PE / PVC Proof Pressure:3.0Mpa | 435psi.Seal O-ring:NBR/ Lock Claw:Nickle-Plated Brass /Body:Nickle-Plated Brass Working Temperature:0-60°C | 32～140°F/Negative Pressure:-100Kpa | -29.5 In Hg
Beduan Pneumatic Fittings are a compact one piece push-to-connect fitting.

All items in the Beduan Pneumatic composite range are silicone free.

The Nickle-Plated Brass gripping ring ensures excellent tube retention while the D seal

within the fitting provides a positive seal on the O.D. of the tube,

in both static and dynamic positions, due to an optimized design of the fitting cavity.

Beduan Pneumatic composite should not be used for live swivel applications

Body and collar are made of Nickle-Plated Brass , gripping ring is Nickle-Plated Brass , and D seal and O-rings are Nitrile.
