GE Lighting Magnetic Contactor, 120VAC Coil Volts, Contactor Type: Electrically Held, Number of Poles:

GE Lighting Magnetic Contactor, 120VAC Coil Volts, Contactor Type: Electrically Held, Number of Poles:

Lighting Contactors Rated 30A inductive and resistive 7.4"H x 4.2"W x 3.9"D Electrically heldDesign allows additional power poles to be added to a max. of six 1 or 2-pole blocks. Poles are supplied in the NO position on contactor. Up to 4 power pole blocks are field convertible to NC. RoHS Compliant. UL Listed. Mechanically held contactors have built-in control module delays to minimize excessive operation from faulty control devices.

Item: Lighting Magnetic Contactor
Number of Poles: 2
Coil Volts: 120VAC
Full Load Amps: 30
Contactor Type: Electrically Held
Enclosure NEMA Rating: No Enclosure
Height: 7.40"
Width: 4.20''
Depth: 3.90"
Hz: 50/60
HP @ 1 Phase - 120V: 1
HP @ 1 Phase - 240V: 2
HP @ 3 Phase - 208V: 3
HP @ 3 Phase - 240V: 5
HP @ 3 Phase - 480V: 10
HP @ 3 Phase - 575V: 15
Standards: UL 508 File, E1811 Vol 19, cUL, CE
