TIME MARK 261D120 Solid State Alternating Relay 120V-AC D636235

TIME MARK 261D120 Solid State Alternating Relay 120V-AC D636235

120 VAC/VDC,DPDT, UL/CSA Solid-state Reliability Heavy-duty Contact Rating Optional Load 1-Load 2 Toggle UL Recognized; CSA Certified Time Mark261-D-120 Alternating Relays Designed for duplex pumping systems Internal electromechanical relay Indicator lights on the case Optional toggle switch versions The Model 261 series Alternating Relay is designed for duplex pumping systems where it is desirable to equalize pump run time. The solid state alternating circuit drives an internal electromechanical relay. A continuous power source and control switch are required. The control switch (float, pressure or other isolated contact) is connected between the L1 terminal and the control terminal. Each time the control switch is opened the output contacts will change states. Indicator lights on the case show the internal relay status. On the optional toggle switch versions, the toggle switch is set to the NORMAL position. Setting the switch to Load 1 or Load 2 will lock the relay in position, preventing alternation.
