NanoPi NEO Open Source Allwinner H3 Development Board Super Raspberry Pie Quad-core Cortex-A7 DDR3 RAM 512MB Run Ubuntu Core

NanoPi NEO Open Source Allwinner H3 Development Board Super Raspberry Pie Quad-core Cortex-A7 DDR3 RAM 512MB Run Ubuntu Core

Wiki: Wiki: “youyeetoo.com/blog/nanopi-neoys0001-195” (Hardware Differences Among Different Versions please see wiki page) Especially the Debug_UART position. More quetions please email us by click the "WayPonDEV" and ask a question. -Specification- CPU Model: Allwinner H3 Number of Cores: Quad-core Frequency: 4x Cortex-A7 Up to 1.2GHz Memory: RAM: 256MB/512MB Storage: MicroSD Slot: MicroSD*1 for external storage up to 128GB Connectivity: Ethernet: 10/100M Ethernet Audio: Audio input/output Port: 5Pin, 2.0mm pitch pin header USB MicroUSB*1: MicroUSB 2.0, OTG and Power In, Type A USB Host: 2.0 Type A*1, 2.54 mm pin*2 Pin-header GPIO: 2.54mm pitch 36pin. It includes UART, SPI, I2C, IO etc Serial Debug Port: 2.54mm pitch 4-pin-header Audio input/output Port: 2.0mm pitch 5-pin header LED Power LED(Red)*1 System LED(Green)*1 Others: Working Temperature: -20℃ to 70℃ Power: DC 5V/2A -OS Support- FriendlyCore 16.04(based on UbuntuCore-16.04) FriendlyCore Focal (Base on Ubuntu 20.04) FriendlyWrt 19.07.1(32-bit) Armbian DietPi Lakka Kali -Kernel version- Linux-4.14-LTS U-boot-2017.11 -Dimension- PCB: 4 Layer Dimension: 40*40mm Weight: 14g(WITHOUT Pin-headers) -In the Box- NanoPi NEO 512MB with Pin x1
