AQD-19 Hand-held Pneumatic Strapping Tools Plastic Pneumatic Strapping Tool For 1/2"-3/4" PP &PET strapping

AQD-19 Hand-held Pneumatic Strapping Tools Plastic Pneumatic Strapping Tool For 1/2"-3/4" PP &PET strapping

【High Efficient】The high degree of automation, tight, controlled fusion crust strong.Easy to use, light weight machine, pneumatic power design. No fasteners, using friction heat welding, the interface appearance and reliable. 【Usage】 The AQD-19 is used to cut lightweight polyvinyl chloride packaging tapes with a thickness of 0.5~0.7mm; The heavy-duty cutter consists of a fixed cutter and a movable cutter. Used to cut zip ties with a thickness of 0.5-1.5mm; Tension 3500N (at 0.63mpa) 【 Air source 】Confirm that the pressure supply pipe can withstand pressure and is oil resistant. Special quick connect fittings must be used, and the air pressure must not exceed 100psi/7 bar. It is prohibited to use any other air source or power source other than clean compressed air 【Application】 This tool is specifically designed for bundling items with PET zip ties, with a width range of 13, 16, and 19mm; Do not use zip ties for lifting purposes 【Maintenance】The packaging machine needs good maintenance; Regularly inspect and use a dust blower to remove dust; Tighten the screws on the suspension hook; When replacing parts, the air source should be cut off: Features:
1. Easy to use, light weight machine, pneumatic power design.
2. No fasteners, using friction heat welding, the interface appearance and reliable.
3. the high degree of automation, tight, controlled fusion crust strong.
4. large tightening force, the special structure design, easy steel, aluminum, heavy-duty packaging tighten and packaging.
5. machine durability, all of the body and components are made of high strength alloy materials, high-reliability design, advanced manufacturing technology.
6. patented design, the use of safe, non-fatigue design.
Technical Datas
Model: AQD-19
Band width: 13-19mm
Band thickness: 0.5-1.5mm
Suitable band: PP &PET strapping
The form of sealing: Frictional heat welding
Max tension: 3000N
Pressure: 0.5-0.7MPa
Weight: 3.8kg
Machine dimension: 280*160*180mm
