USB 4 Channels (10A) Relay Module, for Home Automation - v2

USB 4 Channels (10A) Relay Module, for Home Automation - v2

High quality 4 SPDT Relays RAS-05-15 (10A / 250VAC, 15A / 120VAC, 15A / 24VDC) Power supply: from USB port (consumption - 400 mA, when all relays are on) Windows/Linux free software Software examples: VB.NET, Labview, C#.NET, C++.NET Description The second version of our popular USB 4 Relay Board with several improvements. It comes with MCP2200 chipset, 4 SPDT Relays each rated with up to 10A, relays states saving in internal EEPROM and improved USB interference resistance. Suitable for home automation applications, hobby projects, industrial automation. The free DRM software allows to control relays manually, create timers (weekly and calendar) and multivibrators, use date and time for alarms or control from command line. We provide various software examples: VB.NET, C#.NET, C++.NET, LabVIEW 2011.

Features:
* 4 Digital I/O lines
* Power supply: from USB port
* Significant resistance against USB interference
* Keeps the relay states in internal EEPROM on every toggle
* Power led
* Relay leds
* Size: 77mm x 56mm x 17mm
* Temp Range: -40 to +80 °C
* PCB parameters: Extra PCB openings for better voltage isolation and doubled high voltage tracks
* Footprint is fully compatible with our previous USB 4 Relay Board with FT245RL for easy integration or replacement
* Supported by DRM software (Windows, Linux, Raspbian): Yes
* Supported by Denkovi Command line tool (Windows, Linux, Raspbian): Yes

Documentation:http://denkovi.com/Documents/USB4v2/current-version/UserManual.pdf

Denkovi command line tool: http://denkovi.com/denkovi-relay-command-line-tool
Denkovi Relay Manager: http://denkovi.com/drm-software
For software examples: please contact with us.
